Technical Specifications
| Specification | Value |
|---|---|
| Model No. | UM29-BIKE-01 |
| Frame material | Aluminum Alloy |
| Wheel size | 29'' |
| Fork | S.R. Suntour, Hydraulic Suspension, SF20-XCM-PM-DS-HLO-29-100, 29"，25.4*28.6*175mm threadless, travel 100mm, w/lockout |
| Handle Bars | Aluminum Alloy, φ22.2*φ31.8*760W/B=6°/H=20, comply w/ EN STD |
| Stem | Aluminum Alloy, φ28.6*φ31.8/H=40mm/EXT=60MM/7 degre, comply w/ EN STD |
| Rear Shift Lever | Microshift SL-M819-R, 9 speed |
| Rear Derailleur | Microshift RD-M619M 9 speed, long cage |
| Freewheel/ Cassette | Microshift CS-H093, 9 speed, cassette 11-42T |
| Chainwheel/Crank | Prowheel C10Y-NW, 1/2*3/32*32T*175mm |
| Chain | D99, 1/2*11/128*116L |
| Wheel | Aluminium alloy, 29*H18mm/32H*14G/A/V nozzle |
| Front Hub | Aoyang GL-B43F-QR, M9*100*108mm/14G*32H/disc brake |
| Rear Hub | Aoyang GL-B43R-QR 10S, M10*135*145mm/14G*32H, 10S cassette /disc brake, alloy |
| Tyre | CST C1846, 29*2.40, black tyre |
| Front Brake | C.Star BR-CX7, mechanical disc brake, rotor 180 |
| Rear Brake | C.Star BR-CX7, mechanical disc brake, rotor 160 |
| Grips | TC-G209, 132MM/132MM |
| Saddle | Ergonomic, comply w/ROSH STD |
| Seat post | Aluminum Alloy, φ30.4*400*2.5T, w/Minimum Insertion Mark, comply w/EN Std |
| Pedals | HF-895B Flat pedals, Aluminum Alloy, w/AS/BS Reflector |
| Reflectors | Front- white/ rear- red / wheel - white reflectors, comply w/AS BS CPSC Std |
